2193
2193.2
TK 2/K BG
Disconnect terminal, Screw connection, Mounting type:Mounting rail TS 35/7.5 and TS 32, Rated cross-section: 4 mm², Width: 8 mm, Colour: Beige
Technical data
- Rated current
- 4 A
- Rated voltage
- 300 V
- Connection principle
- Screw connection
- Colour
- Beige
- Width
- 8 mm
- Length
- 57.5 mm
- Mounting type
- Mounting rail TS 35/7.5 and TS 32
- Connection position
- Lateral
- Connections
- 2
- Contamination degree
- 3
- Design of longitudinal partition
- Swivelling
- EU-POP compliant
- Yes
- End plate required
- Yes
- Flammability class UL 94
- V-2
- Gauge plug acc. to EN 60 947-1
- A4
- Height TS 32
- 45.5 mm
- Height TS 35/7.5
- 41 mm
- Insulating housing
- Polyamide 6.6
- Maximum power dissipation for nominal condition
- 0.13 W
- Number of levels
- 1
- Number of terminals per level
- 2
- Overvoltage category
- III
- PROP 65 compliant
- Yes
- REACH CAS 1 Number
- 7439-92-1
- REACH CAS 1 percentage, max.
- 4 %
- REACH CAS 1 percentage, min.
- 0.1 %
- REACH Candidate Substance Note
- No
- REACH compliant
- Yes
- REACH reference date
- 2026-02-04
- Rated impulse voltage
- 6 kV
- RoHS Exception rule
- 6c
- RoHS compliant
- Yes
- Screw head
- Slotted
- Screw threading
- M 3
- Stripping length
- 9 mm
- TSCA compliant
- Yes
- Tightening torque, max.
- 1 Nm
- Tightening torque, min.
- 0.5 Nm
- UL Recognized
- 1
- UL Usegroup B: rated current
- 16 A
- UL Usegroup B: rated voltage
- 600 V
- UL Usegroup C: rated current
- 16 A
- UL Usegroup C: rated voltage
- 600 V
- UL approval
- UL 1059
- UL factory wiring
- Yes
- UL field wiring
- Yes
- UL torque
- 7 Lb In
- UL wire cross-section single-core (rigid) AWG, max.
- 12
- UL wire cross-section single-core (rigid) AWG, min.
- 22
- UL wire cross-section stranded AWG, max.
- 12
- UL wire cross-section stranded AWG, min.
- 22
- UL wire material
- Cu
- Weight per piece (including packaging)
- 16 g
- Weight per piece (not including packaging)
- 15.2 g
- Wire cross-section AWG, max.
- 12
- Wire cross-section AWG, min.
- 22
- Wire cross-section single core (rigid)/stranded, max.
- 4 mm²
- Wire cross-section single-core (rigid) / stranded, min.
- 0.2 mm²
- Wire cross-section stranded with wire-end ferrule, min.
- 0.2 mm²
- Wire cross-section stranded with wire-end ferrules, max.
- 2.5 mm²
- Wire cross-section stranded, max.
- 4 mm²
- Wire cross-section stranded, min.
- 0.2 mm²
- Working temperature, max.
- 105 °C
- Working temperature, min.
- -40 °C
Commercial data
- Country of origin
- DE
- Customs number
- 85369010
- GTIN (EAN)
- 4044211050191
